Introduction

Dental trauma is a frequent situation in Pediatric Dentistry practice and may become a traumatic experience for parents and children. As a result, such episodes require the professional dentist to master the technical procedures and the psychological ability to transmit security during emergency care¹.

Traumatic injuries occur in the teeth and supporting structures and may result in fractures, dislocations, and injuries to the gums and mucosa². Children affected by traumatic injuries experience unpleasant experiences of pain and discomfort, in addition to generating an impact on quality of life, due to loss of function and aesthetic impairment³.

The prevalence of dental trauma in childhood is high. Approximately one- third of toddlers and preschool children suffer episodes of dental trauma in primary teeth³. Children ranging from 1 to 3 years old are vulnerable to traumatic injuries because they are beginning to walk and socialize.⁴

Traumatic dental injuries may be classified according to the tissues involved, such as: soft tissues, dental hard tissues and pulp and supporting tissues⁵. In primary teeth, supporting tissue injuries are the most frequent type of dental trauma due to the elasticity and porosity of the alveolar bone and lower crown-root- relation⁶. Dental hard tissues and pulp lesions are more common in permanent dentition.⁷

Intrusive dislocation or tooth intrusion is the most frequent type of traumatic injury in primary dentition, with a prevalence of 1.5%⁸ to 7%⁹. This lesion results from dental trauma with an axial dislocation of the tooth into the alveolar bone⁵. Clinically, intrusive dislocation is classified, according to the visible portion of the dental crown, in: grade I - mild partial intrusion in which more than 50% of the crown is visible; grade II - moderate partial intrusion in which less than 50% of the crown is visible; grade III - severe or complete intrusion of the crown.¹⁰

The treatment of intrusive dislocation involves longitudinal clinical and radiographic follow-up. Generally, the tooth returns to the normal position within 6 months, although in some cases, it can take up to a year for its complete re-eruption¹¹. For this reason, the correct diagnosis of dental trauma, physical examination, thorough radiographic examination and longitudinal follow- up are essential for the success of the prognosis and chosen treatment.^12-14

This study aims to report a clinical case of intrusive dislocation in the primary dentition, involving diagnosis and longitudinal clinical and radiographic follow-up. Informed consent was obtained and signed by the parents of the child.

Case Report

Male patient, 3 years old, attended in Emergency of the Children's Specialty Clinic - State University of Londrina (UEL), due to the occurrence of dental trauma in the anterior-superior region. In the anamnesis, the child's mother reported that the patient fell from on the same level and hit his mouth on the handlebars of a scooter. In addition, the mother reported slight bleeding from the gums and the child was medicated with analgesics and anti- inflammatory drugs. The interval between the accident and the clinical examination was three days.

In the first appointment, clinical and radiographic examinationswere performed. Was observed swollen gums in the region of the upper incisors, was observed tooth #61 was intruded, with a third of the crown visible (grade II) and mild intrusion of tooth #62, with more than a third of the crown visible (grade I) (Figure 1A ).

Radiographically, (modified periapical anterior and Fazzi’s lateral radiograph), teeth #61 and #62, without fracture of the bone plate and injury to the germs of

Figures 1A y 1B  Clinical and radiographic aspects of intrusive

Figure 2 Fazzi’s lateral radiograph.

the permanent teeth (Figures 1B and 2). The treatment of choice was to wait for spontaneous teeth re-eruption.

The immediate treatment performed was symptomatic, with the prescription of V.A.S.A. (gentian violet) to be applied to soft tissues and brushed with 0.12% chlorhexidine digluconate for 7 days. 3A Clinical and radiographic lollow-up was established after 1 week, 6-8 weeks, 6 months, 1 year and after eruption of permanent teeth, according to the International Association of Dental Traumatology (IADT) trauma guidelines. Parents were informed about the risk of discoloration, root resorption and especially pulp necrosis of traumatized teeth in cases of dental intrusion. In addition, they were instructed about occlusal interferences harmful to the re-eruption of teeth, such as: use of a pacifier and bottle, nail-biting habits, biting objects and sucking a finger, as well as avoiding biting hard food with the front teeth.

On clinical examination after 7 days, redness and swelling of the gingival mucosa was observed. There was no mobility #61 and #62, and #61 with a third of the crown visible. On clinical and radiographic examination after two weeks, it was possible to observe a mild re-eruption of the dental elements (Figures 3A and 4B).

After 60 days, tooth #61 almost completely re-erupted and #62 completely re-erupted (Figures 4A and 4B), without color change,

Figures 3A y 3B Clinical and radiographic aspects after two weeks following trauma showing the beginning of the re-eruption process.

complaints of pain, inflammation or fistula. In addition, the gums looked healthy. Radiographically, there is no observed presence of periapical and periodontal lesions (Figure 4C). On the 8 months follow-up, it was found that tooth #61 re erupted satisfactorily, despite being slightly above the line of occlusion and the patient presenting an anterior open bite. Absence of gingival inflammation, fistula or pain was

Figures 4A,4B y 4C  Clinical and radiographic aspects after 2 months following trauma with complete re- eruption of teeth.

also observed (Figure 5A). Besides, dental biofilm accumulation, redness and swelling in the gingiva inserted around tooth #62, with gingival recession at the cervical level due to occlusal interference, grade I mobility and external root resorption was noted (Figure 5B). On radiographic examination, no signs of periapical and periodontal lesions in tooth #61 was observed. The patient was asymptomatic and there was no need for intervention. On 12-month clinical and radiographic follow-up, the patient returned for a new evaluation and was noted to have the same characteristics as the last follow-up (Figures 6A and 6B).

Figures 5A y 5B  Clinical and radiographic aspects after 8 months following trauma.

The child's mother reported that the child still uses a bottle and pacifier and does not feel discomfort in tooth #62. Again, hygiene instructions and guidance on the child's deleterious habits were given. The

Figures 6A y 6B  Clinical and radiographic aspects after 1-year following trauma.

mother received information about root resorption of the upper left lateral incisor, which should be extracted at any sign of inflammation, infection or pain. The patient will continue to be monitored by the Oral Health Program at the Department of Pediatric Dentistry at the State University of Londrina.

Discussion

Intrusive dislocations are the most common type of trauma in the primary dentition¹⁵ and affect mainly the age group between 1 and 3 years old¹⁶. In relation to gender, in a study performed by ^{Soporowski, Allred and Needleman (1994)}, a prevalence almost twice as high in boys was observed¹⁷. On the other hand, ^{Moura et al. (2011)} and ^{Altun, Esenlik and Tozum (2009)} did not observe gender differences^18,16. Among the most frequent causes are falls and accidental collisions¹⁹, with the anterior-superior teeth being the most affected^20,21. Behavioral characteristics and presence of malocclusion are also among the predisposing factors for trauma²².

The diagnosis of dental trauma requires careful and detailed examination based on care and updated protocol. Thus, on the clinical exam, detailed information should be acquired about the history of the trauma, medical history, presence of previous trauma, systemic manifestations and painful symptoms. It is also necessary to assess the general condition of the patient and the signs and symptoms that may indicate the occurrence of lesions to the central nervous system, such as nausea, vomiting and amnesia. In these cases, it is necessary to refer the patient to the nearest hospital²³.

Radiographic examination is also essential in cases of dental trauma involving the supporting tissues, to assess the root condition, the relationship with adjacent structures and the existence of periapical lesions, bone fragments and foreign bodies. The most used radiographic techniques in intrusive dislocations are modified anterior periapical and Fazzi's lateral, which make it possible to evaluate the direction of tooth palatine or buccal displacement²⁴.

Treatment of dental trauma is a theme discussed in the literature that involves several factors, such as: time elapsed between the dental trauma and seeking treatment, age of the patient, degree of tooth mobility. One option recommended to treat a deciduous intruded tooth is to await spontaneous re eruption that can happen within six months or even a year¹¹.

Pulp necrosis and coronal discoloration are the most observed sequelaes in the deciduous dentition after dental trauma²⁵. When the discoloration is accompanied by changes, such as: internal root resorption, inflammatory root resorption or by replacement, periapical inflammation or fistula, the deciduous tooth must be treated endodontically²⁶. In the present study, until now, no signs or complications were observed in the pulp tissues.

Infection control in the deciduous dentition is an important factor because the wide medullary spaces favor the spread of infection and the development of the permanent tooth germ occurs very close to the roots of these teeth, which can also lead to sequelae in the permanent successor²⁷. Because of this, the preservation of the healthy deciduous tooth until the eruption of the permanent successor is essential for the maintenance of the esthetics, the function and the length and symmetry of the arch²⁸.

Generally, the re-eruption process happens after a few weeks. An ankylosis process may be present when tooth movement does not occur between 1 and 6 months and the tooth must be extracted²⁹. According to ^{Costa, Corrêa and Ribeiro (2005)}, re-eruption presents in 95% of cases in the first six months, and it is important to evaluate the pulp and periodontal condition after this period⁷. Therefore, according to ^{Carvalho, Jacomo and Campos (2010)}, the frequency of tooth extraction while waiting for the intruded deciduous tooth to re-erupt is low, being approximately 25%¹⁴. Therefore, it is essential to establish a protocol for observation and control of the traumatized tooth, while waiting for the re-eruption of the intruded tooth, observing signs and symptoms of the tissues involved.

Parents should be advised about the importance of returning if an unfavorable prognosis is observed and about the possible sequelae resulting from the dental trauma, such as: pulp necrosis, bone resorption, ankylosis and damage to the development of the permanent tooth germ³⁰. In addition, parents should also be informed about care with food and the non-use of artificial teats (pacifier and/or bottle) after the dental trauma³¹.

Furthermore, the application of V.A.S.A. for treatment and analgesia of soft tissues may be performed³². In cases of fever or bone exposure, analgesics and antibiotics should be prescribed respectively²⁹.

In the present study, it was decided to monitor the re-eruption of intruded dental elements, according to the protocol established by the guidelines of the International Association of Dental Traumatology - IADT¹¹. We did not opt for extraction because of concern that damage to the permanent tooth bud may occur during the procedure, as well as the lack of evidence that immediate extraction will reduce damage to the permanent tooth bud. Additionally, the tooth should be allowed to reposition spontaneously, irrespective of the direction of the displacement. Spontaneous improvement in the position of the intruded tooth usually occurs within six months but can take up to one year in some cases³³. The conservative treatment spontaneous recovery of intrusive luxations due to trauma can have satisfactory results, after an evaluation and analysis of all determining factors, avoiding procedures and negative consequences for the patient.³⁴

Around three weeks after the trauma, the teeth began to erupt, which is in line with the clinical findings by IADT^¹¹, which suggest the onset of re-eruption between 2 and 4 weeks. By 8 months, the tooth #61 had completed their full re-eruption. The present clinical case illustrates the relevance of protocols on dentoalveolar trauma and confirms the need for longitudinal clinical and radiographic maintenance, and that cases of intrusive dislocation can present potential inherent complications in the deciduous and permanent. Furthermore, we highlight the fact that emergency consultation in the decoration of dentoalveolar trauma is effective, assertive and based on the best scientific evidence. The pediatric dentist must be able to integrate children and the family nucleus and share information and guidance on the importance of changing the strengths of current oral habits, as well as raising awareness of the importance of longitudinal conservation.

Conclusion

It is essential the correct diagnosis, conduct and follow-up in cases of dental trauma, aiming to reduce the possible sequelae in deciduous and permanent dentition.
