Introduction

Dentoalveolar trauma (DT), situation commonly found in childhood, represents a public health problem with potential compromises to the quality of life of children and families in social and psycho-emotional areas.^1,2 In order to reduce these impacts and restore the function and aesthetics of the fractured tooth, autogenous, homogeneous bonding or direct composite resin (CR) restoration represent restorative treatment options.

The choice to perform a direct restoration, due to the polychromatic nature of the teeth, makes the selection of CR shades an important and challenging clinical step. Therefore, the layering technique is widely used as it provides aesthetic results that are more similar to natural teeth. Nonetheless, in Pediatric Dentistry, the patient profile often requires the option of simpler materials and techniques, which consume less clinical time without, however, compromising the quality of the result achieved.^3,4

To meet this clinical need, monochromatic composite resin (MCR), indicated for the restoration of anterior and posterior teeth, are sold in a reduced number of shades, have modified optical properties that result in the ability to mimic the color of the restored dental substrate, such as a chameleon effect, and, consequently, in the creation of high aesthetic performance restorations.^5,6 However, MCR is considered a new material and requires further laboratory and clinical studies to prove predictability, efficacy and longitudinal performance. Therefore, the aim of the present study is to present and discuss the direct restoration technique for upper central incisors with crown fractures resulting from DT using MCR, as well as longitudinal clinical follow-up of the case.

Case report

An 8-year-old male patient attended the Emergency Children's Dental Care at the Children's Specialties Clinic-Baby-Clinic of the State University of Londrina, for immediate treatment after a fracture in the right upper central incisor due to a fall during a school sports activity. On intraoral physical examination, a coronal fracture of the enamel and dentin was diagnosed without involvement of the pulp tissue (Figure 1). Response to the vertical and horizontal percussion test was not suggestive of endodontic and periodontal alterations, respectively, and impairment of the periodontal insertion was also ruled out through the mobility test in the buccal-palatal direction.On radiographic examination (Figure 2) confirmed the absence of periodontal and periapical involvement, as well as the absence of root fracture.

The urgent clinical management was, as follows: cleaning the exposed dentin of the fractured tooth with 0.12% chlorhexidine (Perioplak, Reymer, Aparecida de Goiânia- GO, Brazil) and temporary restoration with conventional glass ionomer cement (GIC)

Figure 1 Initial clinical condition after dentoalveolar trauma.

Figure 2 Periapical radiograph of the right upper central incisor region.

(Maxxion R, FGM, Joinville-SC, Brazil), to protect exposed dentin and control the sensitivity reported by the patient. At the end of the session, the patient was referred to the Dental Residency program at UEL, to perform the definitive restoration.

In the first clinical session, the upper and lower arches were molded with alginate (Jeltrate Dustless, Dentsply, Pirassununga- SP, Brazil), to obtain the study models. For restorative planning, diagnostic waxing of the right upper central incisor was performed using the progressive technique.

In the following session, direct restoration of the upper right central incisor was performed with MCR (Vittra APS Unique) (FGM Dental Group, Joinville-SC, Brazil). In this occasion, considering the extent of the fracture, a silicone matrix (Perfil, Coltene, Rio de Janeiro-RJ, Brazil) was used to restore the palatal face. The restorative clinical sequence covered: 1) Infiltrative anesthesia, with 2% mepivacaine (adrenaline vasoconstrictor 1:100,000), to remove the GIC, with a #2 Jet carbide drill (Labordental, São Paulo-SP, Brazil), mounted at low speed handpiece; 2) Finishing the enamel in the cavo-surface angle, with diamond tip #1190F (Kavo, Joinville-SC, Brazil); 3) Prophylaxis of the anterior superior teeth with pumice paste and water, with the aid of a Robson brush (Ultra-soft, American Burrs, Palhoça-SC, Brazil); 4) Modified rubber dam isolation; 5) Acid etching of enamel and dentin with 37% phosphoric acid (Biodinâmica, Ibiporã- PR, Brazil), for 30 seconds on enamel and 15 seconds on dentin; 6) Rinsing with a water jet to remove the conditioning agent, for 30 seconds; 7) Drying the operative field with an air jet and the conditioned dentin, with a paper filter (Melitta, São Paulo-SP, Brazil); 8) Application of two layers of the adhesive system (AS) (Adper Single Bond 2, 3M ESPE, Sumaré-SP, Brazil), with the aid of a micro-applicator brush (Cavibrush regular, FGM, Joinville-SC, Brazil), actively, for 15 seconds; 9) Removal of excess AS with the aid of a clean micro-applicator brush and time interval for solvent evaporation; 10) Light cure of the AS with a Radii-Call- SDI device (Southern Dental Industries, São Paulo- SP, Brazil), with an irradiance of 1200 mW/cm2, for 20 seconds; 11) Positioning of the silicone matrix (Figure 3) to restore the palatal face, based on the insertion of the MCR Vittra APS Unique (FGM Dental Group, Joinville-SC, Brazil), and light cure with the LED-based device; 12) Using the incremental technique, with the aid of an insertion spatula and brush, the area corresponding to the dentin was restored with MCR Vittra APS Unique (FGM Dental Group, Joinville-SC, Brazil) with characterization of the volume and anatomy (grooves development) of this substrate (Figure 4). MCR was also inserted over the cavo-surface angle to mask the

Figure 3 Silicone matrix in position to assist in the restoration of the palatal face.

transition line between the tooth and the restored area until the entire buccal surface was completed. All CR increments were light-cured for 40 seconds; 13) Immediate finishing of the proximal surface with a #12 scalpel blade (Feather Safety Razor, Osaka, Japan), on the palatal surface with multi-bladed drill #9406 (Microdont, São Paulo-SP, Brazil) and on the buccal surface with sanding discs (Diamond Master, FGM Produtos Odontológicas, Joinville-SC, Brazil) (Figure 5).

Figure 4 Clinical condition after restoration of the area corresponding to dentin and characterization of the development grooves.

Figure 5 Restoration of tooth 11 after finishing and final polishing.

After a week, the characterization (texturing) of the buccal surface was carried out using diamond-coated (No. 3195F, KG Sorensen) carbide burs (No. 9714 FG, Microdont), silicon impregnated polishers and brushes (Jiffy polishers, Ultradent Products), and a felt disc (Diamond Flex, FGM Dental Group) in association with an aluminum oxide-based polishing paste (Diamond R, FGM Dental Group). The patient underwent clinical and radiographic follow-up sessions after 1 month, 6 months and 10 months (Figures 6 and 7), when, considering his age and need for multidisciplinary intervention, he was referred to the Integrated Children's Clinic for treatment of the upper left central incisor, which was impacted and had no space for eruption. The orthodontic

Figure 6 Periapical radiograph of region of tooth 11 at 10-month follow-up

Figure 7 Clinical condition of tooth 11 in a 10-month follow-up

treatment plan proposed to the patient was the installation of a posterior fixed expansion device to expand the arch with the aim of gaining space, followed by orthodontic traction of the incisor with overwire through the fixed device.

Discussion

The use of CR with charge particles on a submicrometric, monochromatic scale, capable of mirroring the color of the restored tooth like a chameleon effect, in addition to providing practicality for carrying out restorative treatment in a pediatric dentistry patient, also proved to be an excellent option considering performance, aesthetics throughout the follow-up period.

The clinical case presented confirms the high incidence of DT in permanent teeth of male children. At this stage of motor and cognitive development, children are more active, a fact that, combined with poor lip sealing and accentuated overjet, leaves the upper anterior teeth more vulnerable to traumatic injuries.^7,8

The fractured tooth, resulting from DT, could have been restored using the autogenous bonding technique of the tooth fragment. Nonetheless, the conservative treatment option for the coronal remnant, which was low-cost and suitable for maintaining the anatomical, functional and aesthetic characteristics of the tooth, was not carried out as the coronal fragment did not present favorable conditions. It is important to highlight that autogenous bonding has, as unfavorable consequences, the possibility of detachment of the fragment, especially in patients with parafunctional habits of the anterior teeth, and/or the inadequate positioning of the fragment in relation to the coronal remnant, which makes the line of union between fragment and coronary remnant evident.⁹ Indirect restoration was a discarded treatment option based on the patient's age, quality and quantity of the coronary remnant. The creation of an indirect restoration would require wear of the healthy tooth structure, creation of a temporary restoration and laboratory steps, therefore, cost to those responsible for the patient and greater clinical time for construction.^10,11 Based on these considerations, the case was resolved through the creation of a direct restoration with CR.

Direct restoration with CR requires the professional to have skill and knowledge regarding the morphological characteristics of the area to be restored. It is a minimally invasive clinical option, low cost to the patient and capable of being performed in a short period of time. Although it can be performed by free-hand technique, in the reported clinical case, a silicone matrix was used to assist in the creation of the palatal face, obtained from the waxed plaster model. The silicone matrix helped control the CR volume necessary for the restoration of the palatal face and incisal edge, as well as establishing extremely relevant anatomical parameters and predictability in the results achieved. Therefore, in the case of pediatric dentistry patients, it is important to highlight that the silicone matrix reduced the clinical time needed to carry out the restoration, finishing and polishing of the palatal face.^4,12 The entire restorative procedure was performed under modified absolute isolation of the operative field, as a convenience for maintaining the operative field dry during insertion, photoactivation of polymerization and initial finishing of the CR.

Considering the patient's age, the selection of CR, with different degrees of opacity and translucency, would be an important and challenging clinical step. Therefore, a MCR capable of mimicking the color of the restored dental substrate was selected as a chameleon effect. Thus, the composite made the procedure easier for the operator and optimized clinical time. In the private service, the option for a MCR may impact the cost of treatment.

MCR achieves mimicry thanks to its chromatic mirroring characteristics, in which, due to the presence of more transparent photo-initiators and a low concentration of camphorquinone, they allow for easier color transmission. To understand the process, it is important to consider that color is typically classified as a chemical or structural phenomenon. The chemical mechanism is based on pigments that selectively absorb some wavelengths of light, while reflecting others, this being the process commonly found in photopolymerizable CR.^13,14

Structural color is not related to pigments. It is a physical phenomenon due to the superficial optical action of diffraction of nanometric structures,¹⁵ in which colors are produced by submicrometer structures that reflect light at one wavelength.¹³

MCR Vittra APS Unique (FGM Dental Group, Joinville-SC, Brazil) is a nanohybrid composite with spherical charges and has the property of transmitting light without diffusion. The phenomenon of structural color occurs due to the shape and size of the particles, which are precisely uniform, improving the color adjustment to the surrounding dental substrates in the range from yellow to red by the effect of amorphous aggregates. Development in the yellow to red range can contribute to improving restoration color matching in a complex way, where color adaptation is influenced by cavity size and depth.^13,14

In a clinical case of tooth fracture, the manufacturer of the MCR recommends the insertion of a body CR to restore the palatal face, prior to the insertion of the MCR increments, to support the color. However, in the reported case, considering the CR volume, in bucco-palatal thickness, it was decided to insert only the MCR to restore saturation, opacity and color perception. After 10 months of follow-up, considering the criteria: color, adaptation and marginal pigmentation, polishing and surface texture, fracture, secondary caries and sensitivity,¹⁶ the treatment performed demonstrates satisfactory aesthetic, biological and functional results.

Conclusion

The selection of MCR demonstrated satisfactory clinical results for the anatomical and aesthetic restoration of the fractured anterior tooth after DT. The use of MCR, replacing the stratified restorative technique, with the insertion of CR with different degrees of opacity and translucency, made it easier for the operator to perform the procedure and reduced clinical time, which makes it an option of choice in patient care pediatric dentists.
